It is widely used in the line of life sciences, medical and chemical laboratories. It applies to 1.5ml/2.2ml tube and 0.2ml PCR strip tube.
Technical Performance
* LCD screen and small size.
* It operates at low noise levels.
* Brushless motor and energy efficient.
* Sample has low temperature increment in spin, which is less than 10°C after working for 30 minutes.
* Fast acceleration and deceleration level, 12s at most.
* Keypad has a clear structure, it is convenient for operation.
* The rotor has quick-lock cap, which is convenient to install and remove.
* Aluminium rotor are durable and autoclavable.
* It has many safety function and conform to CE safety standards
* Micro tube rotor with aerosol-tight lid ensures a safety operation.
Specification
|
Model
|
H14.5M |
|
Max Speed
|
14500r/min
|
|
Max RCF
|
14000×g
|
|
Max Capacity
|
1.5ml/2.2ml×12
|
|
Speed Accuracy
|
±30r/min
|
|
Time
|
20s-99min
|
|
Noise
|
＜50dB(A)
|
|
Voltage
|
AC220V 50Hz 5A
|
|
Rated Power
|
100W
|
|
Size(L×W×H)
|
230mm×270mm×155mm
|
|
Packing size(L×W×H)
|
285mm×410mm ×220mm
|
|
Net Weight
|
4.8kg
|
H14.5M machine and rotors
|
|
Model
|
Max Speed
|
Max RCF
|
| |
H14.5M |
14500r/min
|
14000×g
|
|
NO.1 Angel rotor
|
1.5ml/2.2ml×12
|
14500r/min
|
14000×g
|
|
No.2 PCR rotor
|
0.2ml×8×4
|
6000r/min
|
2140×g
|
